Low Temperature LCD PDF External Probe Data Logger "LogTag" Model: UTREL-16F

UTREL-16F.

-90°C to +40°C (-130°F to +104°F).

-30°C to +60°C (-22°F to +140°F).

0°C to +40°C (32°F to +104°F).

0.1°C (0.2°F) for measurements -80°C to 10°C (-112°F to 50°F).

0.2°C (0.4°F) for measurements 10°C to 20°C (50°F to 68°F) and -90°C to -80°C (-130°F to -112°F).

0.3°C (0.5°F) for measurements 20°C to 30°C (68°F to 86°F).

0.5°C (0.9°F) for measurements 30°C to 40°C (86°F to 104°F).

LogTag Analyzer® currently displays to one decimal place of °C or °F. The native resolution is what is stored in the LogTag®.

Better than ±0.5°C for -20°C to +10°C (-4°F to 50°F)

Better than ±0.7°C for -50°C to -20°C (-58°F to -4°F) and +10°C to +30°C (50°F to 86°F)

Better than ±1°C for -80°C to -50°C (-112°F to -58°F ) and +30°C to +40°C (86°F to 104°F)

Better than ±1.8°C for -90°C to -80°C (-130°F to -112°F)

16,129 temperature readings.

112 days @ 10min logging, 168 days @ 15min logging. Statistics memory (for display on LCD): Max/Min values and alarm duration values.

Configurable from 30 seconds to 18 hours.

Push button start or specific date & time. Optional start delay.

Three configurable upper and three configurable lower alarms.

“REC” symbol on LCD.

Typically with full memory (16,129 readings) in less than 30 seconds from time of insertion to availability of PDF report.

Typically less than 10 seconds from time of insertion to availability of LTD file in LogTag® Analyzer (if configured).

IP61 (when vertically mounted or hung with USB dust-cap in place).

CR2450 3V LiMnO2 (Fixed battery).

Storage life of 1 year before ‘start’ (if it is hibernation mode), followed by:

2 years of normal use (based on 15 minute logging, download data monthly).

Built-in real time clock.

Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day).

Rated temperature coefficient is -0.034 ±0.006ppm/°C (I.e typically +/- 0.00294 seconds/day/°C).

USB 2.0, A-type plug.

PDF Reader, LogTag® Analyzer 3.1.9 or higher.

Multi-language support for English, Spanish, French, Russian and German.

One page report with trip and alarm summary. Multi-page report with list of readings, including date and time.

93mm(H) x 54.5mm(W) x 8.6mm(T) including protective USB cap.

Polycarbonate.

Built-in real time clock.

Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day).

Rated temperature coefficient is -0.034 ±0.006ppm/°C (i.e typically +/- 0.00294 seconds/day/°C).

Standard: 0.5m (19″).

Extended: 3m (9’10″) (Recommended maximum).

PTFE (FDA food contact rated), coaxial.

93mm(H) x 54.5mm(W) x 8.6mm(T).

41g without External Probe.

Polycarbonate.
