Temperature Data Logger
Temperature Logger "LogTag" Model: TREX-8
Temperature Logger "LogTag" Model: TREX-8
Temperature Logger "LogTag" Model: TREX-8

Temperature Logger "LogTag" Model: TREX-8

สอบถามข้อมูล
02-557-1073
Manufacturer:
LogTag
Availability:
In Stock

The LogTag® TREX-8 is a versatile, wide range, multitrip Temperature Logger with interchangeable External Probes, featuring high resolution temperature readings over a measurement range of -40°C to +99°C (-40°F to +210°F).



Interchangeable Remote Probes – LogTag remote temperature probes are interchangeable provided they are changed with LogTag ST100 type remote temperature sensors.



Using the LogTag® Interface and LogTag’s freely available companion software LogTag® Analyzer, the LogTag is easily set-up for recording conditions including delayed start, sampling interval, number of readings, continuous or fixed number of readings and configuration of conditions to activate the ALERT indicator.



eadings are downloaded using LogTag® Analyzer which provides facilities for charting, zooming, listing data statistics and allows exporting the data to other applications such as Excel.



The LogTag® TREX-8 complies with the relevant international standards for temperature monitoring devices: FCC, CE, C-TICK and RoHS. This demonstrates the quality and suitability of the LogTag® TREX-8 for temperature monitoring applications where accuracy and consistency is required.



Product features:

  • Interchangeable External Probe with high quality gold plated connector.
  • 8000 reading memory capacity with up to 3 year battery life.
  • ‘OK’ & ‘ALERT’ Indicator with high and low customizable alarms.
  • Industry best download time – less than 5 seconds for full memory.



Specification

Product Model TREX-8.
External Sensor Measurement Range

-40°C to +99°C (-40°F to +210°F)
Operating Temperature Range

-40°C to +85°C (-40°F to +185°F).
Storage Temperature Range

-10°C to +55°C (14°F to +131°F).
Rated Temperature Reading Accuracy

Better than ±0.5°C (±0.9°F) for -10°C to +40°C (14°F to +104°F).


Better than ±0.7°C (±1.3°F) for -30°C to -10°C (-22°F to 14°F) and +40°C to +60°C (104°F to 140°F).


Better than ±0.8°C (±1.4°F) for -40°C to -30°C (-40°F to -22°F) and +60°C to +80°C (140°F to 176°F).


Better than ±1.0°C (±1.8°F) for +80°C to +99°C (176°F to 210°F).


Actual performance is typically much better than the rated values.


Accuracy figures can be improved by recalibration.
Rated Temperature Reading Resolution

Less than 0.1°C (0.2°F) for measurements -40°C to +40°C (-40°F to +104°F).


Less than 0.2°C (0.4°F) for measurements +40°C to +80°C (+104°F to +176°F).


Less than 0.6°C (0.5°F) for measurements +80°C to +99°C (+176°F to +210°F).


LogTag Analyzer® currently displays to one decimal place of °C or °F. The native resolution is what is stored in the LogTag®.
Sensor Reaction Time

Typically less than 2 minutes (T90) in moving air (1m/s) for ST100T, ST100H and ST100S types.
Recording Capacity

8,031 temperature readings. 53 days @ 10min logging, 80 days @ 15min logging.
Sampling Interval

Configurable from 30 seconds to 18 hours.
Logging Start Options

Push button start or specific date & time. Optional start delay of up to 72 hours.
Recording Indication

Flashing ‘OK’ indicator / flashing ‘ALERT’ indicator.
Download Time

Typically less than 5 seconds for full memory (8031 readings), depending on computer or readout device used.
Environmental IP61.
Power Source

CR2450 3V LiMnO2 Battery (Fixed).
Battery Life

1 year storage, followed by 2 – 3 years of normal use (based on 15 minute logging, download data monthly).
Real Time Clock

Built-in real time clock.


Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day).


Rated temperature coefficient is -0.034 ±0.006ppm/°C (I.e typically +/- 0.00294 seconds/day/°C).
Standard Remote Sensor Cable Length

Standard: 1.5m (4’11″).


Extended: 3m (9’10″) (Recommended maximum).
Remote Sensor Cable Type

PTFE (FDA food contact rated), coaxial.
Size

86mm(H) x 54.5mm(W) x 8.6mm(T).
Weight

36g (without External Probe).
Case Material

Polycarbonate.
